Champion · Expansion battery
201107
1,638Wh battery capacity for compatible Champion power stations.
Price varies by retailer
Affiliate-ready field · no official direct price published
Visual spec gallery
The important numbers, at a glance.
1,638Wh
Rated battery capacity
Manufacturer runtime
Varies by load
Operating volume
Near-silent battery power
Energy source
Battery
No combustion fuel required
24.9 lb.
Unit weight
13.4 in. × 10.2 in. × 6.7 in.
Length × width × height
- Warranty
- 3 Year (or 1000 Cycles) Warranty
- Starting
- Push-button
- Status
- Listed in Champion U.S. catalog
Starting system
Push-button power
Power system
Battery inverter
Protection
Battery-management protection
Electrical
See full specs
Connection details are included in the full specification table below.
Official product gallery
Product views and Champion infographics.
These manufacturer images may include output comparisons, controls, dimensions, included equipment, and common use cases. Scroll sideways to view the complete official set available for this model.
Complete specifications
Every official field, organized.
The technical fields below come from Champion’s current U.S. model page. Product photos and infographics come from its official gallery. Confirm current documentation and retailer details before purchase.
Manufacturer overview
Features Increase Run Time Connect this additional battery and add 1638Wh to your power station Efficient Li-ion advanced battery technology delivers lasting fade-free power plus you don’t need gas, there’s no engine, and no emissions Versatile Charge your battery to 80% in 2.8 hours AC or solar charge time, or use AC and solar power together and get a quick 1.4 hour charge time Expansion Options Chain up to 10 expansion batteries per power station to add up to 16.3 kWh capacity and dramatically increase run time Save Space Stack expansion batteries on top of the power station or each other (adapter required if stacking multiple batteries, contact customer service to order for FREE) Description The Champion Power Equipment 201107 1638 Wh Lithium Ion Expansion Battery is the perfect solution to increase run time for your Solar Generator Power Station. You can pair up to 10 expansion batteries per power station. Be confident you have plenty of off-grid power for your homestead, ice fishing shack, or hunting cabin. The Easy Connect DC Solar Charge Harness is equipped with 3 MC4 connectors, plus an APP port if you want to use your solar panel to charge your battery directly. The MPPT s
Specifications
- Capacity
- 1638 Wh
- Expansion Battery Chainable
- Yes
- Parallel Capability
- No
- Run Time at 100W
- 16.4 hr.
- AC Charge Time to 80%
- 2.8 hr.
- AC Charge Time to 100%
- 4.5 hr.
- Solar Charging
- Yes (MPPT)
- Solar Connection Options
- MC4, Anderson Powerpole
- AC + DC Charge Time to 80%
- 1.4 hr.
- AC + DC Charge Time to 100%
- 2.3 hr.
- Battery Chemistry
- Lithium-ion NMC
- Low Battery Protection
- Yes
- Simultaneous Recharge & Discharge
- No
- Life Cycles
- 500
- Charging Temperature Range
- 32-113 °F
- Discharge Temperature Range
- 5-104 °F
- ETL Listing
- cETLus
Measurements
- Length
- 13.4 in.
- Width
- 10.2 in.
- Height
- 6.7 in.
- Weight
- 24.9 lb.
Best-fit uses
- Power-station expansion
Standout features
- 3 Year (or 1000 Cycles) Warranty
